1–66 Maintenance and Service Guide
Product Description
5 Rotation disk Rotates the tablet PC clockwise or
counterclockwise while it is connected to the
keyboard.
6 Docking alignment
notches (4)
Help guide the tablet PC and keyboard into
an optional HP Tablet PC Docking Station.
7 Docking connector
pass-through
Enables the optional docking station to be
connected to the tablet PC while the
keyboard is attached to the tablet PC.
8 Pointing stick Moves the cursor and selects and activates
items on the screen.
9 Pointing stick buttons (2) Function like the left and right buttons on an
external mouse.
10 Keyboard latch Slide to lock the keyboard or to release the
keyboard from the tablet PC.
11 Caps lock light When this light is on, the caps lock is on.
12 Num lock light When this light is on, the numeric keypad is
active.
Table 1-53
Keyboard Top Components
(Continued)
Item Component Function
