Product Description
Maintenance and Service Guide 1–69
The components on the rear and bottom of the optional
keyboard are shown in the following illustration and described in
Table 1-55.
Keyboard Rear and Bottom Components
Table 1-55
Keyboard Rear and Bottom Components
Item Component Function
1 Screen protector slots Attach the screen protector to the keyboard.
2 Attachment release
switch
Releases a portfolio or optional screen
protector from the keyboard.
3 Universal alignment slots Secure the portfolio or optional screen
protector to the keyboard.
4 Alignment key slots Accept alignment keys to ensure proper
orientation.
