D Class System Memory Upgrade
Memory Installation Procedure
Memory Load
Order for Models
D200/D210/D310
Memory pair (two 16MB, two 32MB, or two 64MB SIMM cards) must be loaded
onto the Processor/Memory card in the proper load order, starting with the slot
marked 0, then slot 1, and so on, ending with slot 7 (see Load Order in the figure
below).
Memory Module Load Order for Models D200/D210/D310
After you have planned your memory configuration according to the memory size,
orientation, and pairing rules, proceed to step H. Install Memory modules.
NOTE The 256MB and 512MB memory size increments are not supported on the
PA7100LC Processor/Memory cards (Models D200/D210/D310).
