D Class System Memory Upgrade
Memory Installation Procedure
Memory Load
Order for Models
D250/D260 and
D260/D360
Memory modules (two 16MB, two 32MB, two 64MB, two 128MB and two 256MB
SIMM cards) must be loaded in the proper load order, starting with the slots marked
0A and 0B, then slots 1A and 1B, and so on, ending with slots 3A and 3B (see Load
Order in the following figure). Be sure to follow the memory size, orientation, and
pairing rules listed on page 12.
Memory Module Load Order for Models D250/260 and D350/360
After you have planned your memory configuration according to the memory size,
orientation, and pairing rules, proceed to step H. Install Memory modules.
