HP dc5750 - Microtower PC User Manual

Advanced tasks (administrators only)
The “Advanced” page allows you to perform the following tasks:
●
Assign a Java Card PIN
●
Assign a name to a Java Card
●
Set power-on authentication
●
Back up and restore Java Cards
NOTE: You must have Windows administrator privileges in order to display the "Advanced" page.
Assigning a Java Card PIN
You must assign a name and a PIN to a Java Card before it can be used in Java Card Security.
To assign a Java Card PIN:
NOTE: The Java Card PIN must be between 4 and 8 numeric characters.
1. Select Start > All Programs > HP ProtectTools Security Manager.
2. In the left pane, click Java Card Security, and then click Advanced.
3. Insert a new Java Card into the card reader.
4. When the New Card dialog box opens, type a new name in the New display name box, type a
new PIN in the New PIN box, and then type the new PIN again in the Confirm New PIN box.
5. Click OK.
38 Chapter 4 Java Card Security for HP ProtectTools ENWW

HP dc5750 - Microtower PC Specifications

General

Chipset	ATI Radeon Xpress 1150
Audio	Integrated High Definition Audio
Networking	Integrated Broadcom NetXtreme Gigabit Ethernet
Power Supply	300W
Processor	AMD Athlon 64 X2, AMD Athlon 64, AMD Sempron
Memory	Up to 8 GB DDR2 SDRAM
Storage	SATA Hard Disk Drive
Optical Drive	DVD-ROM, DVD+/-RW
Graphics	Integrated ATI Radeon Xpress
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 1 PCI
Ports	4 USB 2.0, 1 RJ-45, 1 VGA, Audio in/out, Serial, Parallel
Operating System	Windows XP, Windows Vista, FreeDOS
Weight	10 kg
