HP dc5750 - Microtower PC User Manual

Assigning a name to a Java Card
You must assign a name to a Java Card before it can be used for power-on authentication.
To assign a name to a Java Card:
1. Select Start > All Programs > HP ProtectTools Security Manager.
2. In the left pane, click Java Card Security, and then click Advanced.
3. Insert the Java Card into the card reader.
NOTE: If you have not assigned a PIN to this card, the New Card dialog box opens, allowing you
to type a new name and PIN.
4. In the right pane, under Display name, click Change.
5. Type a name for the Java Card in the Name box.
6. Type the current Java Card PIN in the PIN box.
7. Click OK.
Setting power-on authentication
When enabled, power-on authentication requires you to use a Java Card to start the computer.
The process of enabling Java Card power-on authentication involves the following steps:
1. Enable Java Card power-on authentication support in BIOS Configuration or Computer Setup. For
more information, see “
Enabling and disabling smart card power-on authentication support
on page 46.”
2. Enable Java Card power-on authentication in Java Card Security.
3. Create and enable the administrator Java Card.
ENWW Advanced tasks (administrators only) 39

HP dc5750 - Microtower PC Specifications

General

Chipset	ATI Radeon Xpress 1150
Audio	Integrated High Definition Audio
Networking	Integrated Broadcom NetXtreme Gigabit Ethernet
Power Supply	300W
Processor	AMD Athlon 64 X2, AMD Athlon 64, AMD Sempron
Memory	Up to 8 GB DDR2 SDRAM
Storage	SATA Hard Disk Drive
Optical Drive	DVD-ROM, DVD+/-RW
Graphics	Integrated ATI Radeon Xpress
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 1 PCI
Ports	4 USB 2.0, 1 RJ-45, 1 VGA, Audio in/out, Serial, Parallel
Operating System	Windows XP, Windows Vista, FreeDOS
Weight	10 kg
