11. Carefully lift the Cartridge Tubes Connector out of the Left Ink Supply Station.
12. Carefully lift the Left Ink Supply Station enough so that you can rotate it counterclockwise to release
the front attachment from the printer.
13. Carefully lift the Left Ink Supply Station completely out of the printer.
NOTE: When you finish installing or replacing this component, you must perform the necessary
Service Calibrations. To find which calibrations you must perform, refer to
Service Calibration Guide to
Removal and Installation on page 170.
Ink Supply Tubes
Removal
288 Chapter 6 Removal and Installation ENWW
