HP DesignJet Z5200 series

2. Begin lifting the Formatter from the printer. Push the clips and provide upward force at the same
time.
3. Lift the Formatter out of the printer.
NOTE: When you install a new formatter follow the instructions provided on the Flyer that
accompanies it to set up the printer.
Hard Disk Drive
Removal and installation
1. Remove the
Formatter on page 296.
2. Unscrew four screws in the formatter.
ENWW Hard Disk Drive 297
