3. Remove the hard disk drive from the formatter by applying force in the direction of the arrow.
4. Insert a new hard disk drive.
NOTE: If you try to insert a previously used hard disk drive, the printer displays a System Error
and will not start successfully.
5. Replace all screws that you removed earlier.
Electronics Module (Main PCA and PSU)
Removal
NOTE: Switch off the printer and remove the power cable.
1. Remove the Left Cover (refer Left Cover on page 188).
2. Disconnect all the connectors on the Electronics Module.
298 Chapter 6 Removal and Installation ENWW
