Left Front Trim
Removal
NOTE: Switch off the printer and remove the power cable.
1. Remove the Front Cover (refer Front Cover on page 177).
2. Remove the Media Output Assembly (refer
Media Output Assembly on page 178).
3. Remove two T-15 screws that secure the Left Front Trim to the printer.
4. Open the Left Ink Cartridge Door.
5. Unclip the Left Front Trim.
ENWW Left Front Trim 181
