3. Carefully slide the Rear Tray out of the printer.
Rear Cover
Removal
NOTE: Switch off the printer and remove the power cable.
1. Remove the Rear Tray (refer Rear Tray on page 194).
2. Remove the Right Cover (refer
Right Cover on page 185).
3. Remove the Left Cover (refer
Left Cover on page 188).
4. Remove ten T-15 screws that secure the Rear Cover to the printer.
5. Remove the Rear Cover from the printer.
ENWW Rear Cover 195
