HP DesignJet Z5200 series

Front Panel
Removal
NOTE: Switch off the printer and remove the power cable.
1. Open the Window.
2. With strong pressure, squeeze the top edge of the front panel enough to release the attachment
clips, and begin rotating the Front Panel vertically in the next step.
3. Rotate the front panel vertically.
ENWW Front Panel 203
