15. Remove the Ink Supply Tubes Support Rail from the printer.
NOTE: When you reinstall the Ink Supply Tubes Support Rail make sure that the attachment lug
is correctly engaged with the right Top Cover Support.
NOTE: When you reinstall the Ink Supply Tubes Support Rail make sure all the attachment
brackets and bonding leads are correctly connected. These are important to avoid electrostatic
interference being generated.
NOTE: When you finish installing or replacing this component, you must perform the necessary
Service Calibrations. To find which calibrations you must perform, Refer to
Service Calibration Guide
to Removal and Installation on page 170.
ENWW Ink Supply Tubes Support Rail 213
