Window
Removal
NOTE: Switch off the printer and remove the power cable.
NOTE: The Window can also be removed with the Top Cover to avoid scratching the Window. To
remove the Window with the Top Cover, refer to
Top Cover on page 205.
1. Open the Window.
2. Remove the two T-15 screws that secure the left Window hinge locking plate to the Top Cover.
3. Remove the left Window hinge locking plate from the Top Cover.
174 Chapter 6 Removal and Installation ENWW
