Operations 22
3. After performing the installation or maintenance procedure, slide the server back into the rack, and then
press the server firmly into the rack to secure it in place.
WARNING: To reduce the risk of personal injury, be careful when pressing the server rail-release
latches and sliding the server into the rack. The sliding rails could pinch your fingers.
Remove the access panel
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: For proper cooling do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize
the amount of time the access panel is open.
Storage Networks
www.storagenetworks.com
Authorized HP Reseller
Spare Parts:
http://www.storagenetworks.com/products/servers/hp/DL380G8/dl380pg8_servers_landing.php

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP DL380P and is the answer not in the manual?

HP DL380P Specifications

General IconGeneral
Product LineProLiant
Rack Height2U
Processor Sockets2
MemoryUp to 768 GB
RAID Levels0, 1, 5, 6, 10, 50, 60
ManagementHP iLO (Integrated Lights-Out)
Server TypeRack
ProcessorIntel Xeon E5-2600 series
ChipsetIntel C600
Memory Slots24
Memory TypeDDR3
Drive Bays25 SFF
Hard Drive InterfaceSAS, SATA
NetworkGigabit Ethernet
Power SupplyRedundant Power Supplies supported
Expansion Slots6 PCIe Gen3 slots
Operating System SupportWindows Server, Linux, VMware
Remote ManagementHP iLO (Integrated Lights-Out)
Form FactorRackmount
