NOTE:

NOTE:NOTE:

NOTE:

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are

ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO

product offerings and requirements.

NOTE:

NOTE:NOTE:

NOTE:

HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start

with a CTO Chassis.

NOTE:

NOTE:NOTE:

NOTE:

FIO indicates that this option only available as a Factory Installable Option.

Step 1: Base Configuration (choose one of the following configurable models)

Step 1: Base Configuration (choose one of the following configurable models)Step 1: Base Configuration (choose one of the following configurable models)

Step 1: Base Configuration (choose one of the following configurable models)

Models

ModelsModels

Models

HP ProLiant DL385G5 Rack CTO Chassis

453060-B21

Factory Integrated Model ships with:

Factory Integrated Model ships with:Factory Integrated Model ships with:

Factory Integrated Model ships with:

(8) SFF Serial Attached SCSI (SAS) Drive Bays

Two Embedded NC373i Multifunction Gigabit Server Adapters

PCI-Express Riser Cage

800 Watt hot plug power supply, CE Mark Compliant

One IEC Power cord

Hot plug fans (fully redundant)

Rack (2U), (3.5-inch)

Step 1A: Choose Storage Controller (must choose only one of the following)

Step 1A: Choose Storage Controller (must choose only one of the following)Step 1A: Choose Storage Controller (must choose only one of the following)

Step 1A: Choose Storage Controller (must choose only one of the following)

Storage Controllers

Storage ControllersStorage Controllers

Storage Controllers

HP Smart Array P400/256 DL38x LP FIO Ctr

NOTE:

NOTE: NOTE:

NOTE:

PCI Express.

405160-B21

HP Smart Array P400/512 DL38x LP FIO Ctr

NOTE:

NOTE: NOTE:

NOTE:

PCI Express.

405162-B21

HP Smart Array E200/128 BBWC Controller

NOTE:

NOTE:NOTE:

NOTE:

PCI Express.

411508-B21

HP Smart Array P600/256 BBWC Controller

NOTE:

NOTE:NOTE:

NOTE:

PCI-X. SA-P600 Controller supports both internal and external drives.

337972-B21

HP Smart Array P600 w/512 FIO Ctrlr

432103-B21

HP Smart Array P800/512 BBWC Controller

NOTE:

NOTE: NOTE:

NOTE:

PCI Express.

381513-B21

HP Smart Array E200/64 FIO Controller

405528-B21

QuickSpecs

HP ProLiant DL385 Generation 5 (G5)

HP ProLiant DL385 Generation 5 (G5)HP ProLiant DL385 Generation 5 (G5)

HP ProLiant DL385 Generation 5 (G5)

Configuration Information - Factory Integrated Models

DA - 13012 North America — Version 19 — June 2, 2009

Page 21
