HP ProLiant DL385 G5 Performance Models
HP ProLiant DL385 G5 Performance ModelsHP ProLiant DL385 G5 Performance Models
HP ProLiant DL385 G5 Performance Models
Standard Memory
Standard MemoryStandard Memory
Standard Memory
4 GB REG PC2-5300 4 x 1 GB installed
Upgrading Memory and Memory Interleaving
Upgrading Memory and Memory InterleavingUpgrading Memory and Memory Interleaving
Upgrading Memory and Memory Interleaving
DIMMs must be installed in identical pairs. Bank interleaving is automatically enabled on a processor node under the following
conditions:
Four single ranked DIMMs populated per node (4 x 512 MB or 4 x 1 GB for example) yields 2-way bank interleaving.
Two dual ranked DIMMs populated per node (2 x 2 GB or 2 x 4 GB for example) yields 2-way bank interleaving.
Four dual ranked DIMMs populated per node (4 x 2 GB or 4 x 4 GB for example) yields 4-way bank interleaving.
If single and dual ranked DIMMs are mixed on the same node, bank interleaving will not be enabled.
Node interleaving can be configured via RBSU if both processors have the same memory footprint and it is independent of bank
interleaving.
DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the banks furthest away from each processor.
Standard Memory Plus Optional Memory
Standard Memory Plus Optional MemoryStandard Memory Plus Optional Memory
Standard Memory Plus Optional Memory
Up to 36 GB memory is available with the standard memory and the optional installation of 4 x 8GB REG PC2-5300 DIMMs
Standard Memory Replaced with Optional Memory
Standard Memory Replaced with Optional MemoryStandard Memory Replaced with Optional Memory
Standard Memory Replaced with Optional Memory
Up to 64 GB of memory is available with the removal of the standard memory and the optional installation of 8 x 8GB REG PC2-
5300 DIMMs.
NOTE
NOTENOTE
NOTE : Chart does not represent all possible configurations.
Memory
MemoryMemory
Memory Slot
SlotSlot
Slot
1
11
1 2
22
2 3
33
3 4
44
4 5
55
5 6
66
6 7
77
7 8
88
8
Standard
StandardStandard
Standard 4 GB
4 GB4 GB
4 GB 1 GB
1 GB1 GB
1 GB 1 GB
1 GB1 GB
1 GB Empty
EmptyEmpty
Empty Empty
EmptyEmpty
Empty 1 GB
1 GB1 GB
1 GB 1 GB
1 GB1 GB
1 GB Empty
EmptyEmpty
Empty Empty
EmptyEmpty
Empty
Optional
OptionalOptional
Optional 36 GB
36 GB36 GB
36 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 1 GB
1 GB1 GB
1 GB 1 GB
1 GB1 GB
1 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 1 GB
1 GB1 GB
1 GB 1 GB
1 GB1 GB
1 GB
Maximum
MaximumMaximum
Maximum 64 GB
64 GB64 GB
64 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB 8 GB
8 GB8 GB
8 GB
Following are memory options available from HP:
1 GB REG PC2-5300 2 x 512 MB Single Rank Kit 408850-B21
2 GB REG PC2-5300 2 x 1 GB Single Rank Kit 408851-B21
2 GB REG PC2-5300 2 x 1 GB Low Power Single Rank Kit 483399-B21
4 GB REG PC2-5300 2 x 2 GB Dual Rank Kit 408853-B21
4 GB REG PC2-5300 2 x 2 GB Low Power Single Rank Kit 483401-B21
8 GB REG PC2-5300 2 x 4 GB Dual Rank Kit 408854-B21
8 GB REG PC2-5300 2 x 4 GB Low Power Dual Rank Kit 483403-B21
16 GB REG PC2-5300 2 x 8 GB Dual Rank Kit 408855-B21
64 GB REG PC2-5300 8 x 8 GB Dual Rank Kit 495605-B21
