Battery
Description Spare part number
Battery 6-cell Long Life Polymer 67 WHr (2.90 Ahr) 918108-855
IMPORTANT: Make special note of each screw and screw lock size and location during removal and
replacement
Before removing the battery, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the base enclosure (see Base enclosure on page 34).
Remove the battery:
1. Disconnect the battery cable from the system board (1).
2. Remove 6 M2.0x4 screws (2), and then lift the battery to remove it (3).
Reverse this procedure to install the battery.
Component replacement procedures 35
