Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
For use in models with a 400 nit display N09821-001
(12) WLAN module
Intel AX211 Wi-Fi 6E Bluetooth 5.2 vPro M53363-001
Intel AX211 Wi-Fi 6e Bluetooth 5.2 M53366-001
(13) Solid-state drive (M2. 2280)
NOTE: The solid-state drive support kit is available as spare part number N00354-001.
1 TB, PCIe, TLC M16560-001
512 GB, PCIe-4 × 4, TLC M17436-001
512 GB, PCIe-4 × 4, TLC, self-encrypting drive M52031-001
512 GB, PCIe, value L85364-001
256 GB, PCIe-4 × 4, TLC M52025-001
256 GB, PCIe-4 × 4, TLC, self-encrypting drive M52029-001
256 GB, PCIe, value L85354-001
(14) Real-time clock (RTC) battery M34737-001
(15) Fingerprint reader
NOTE: The ngerprint reader cable is available in the Cable Kit as spare part number M21138-001.
The ngerprint reader insert (for use on models without a ngerprint reader) is available in the
Plastics Kit as spare part number N00113-001.
N00879-001
NFC module (not illustrated)
NOTE: The NFC cable is available in the Cable Kit as spare part number M21138-001.
NOTE: The NFC module spare part kit does not include the antenna. The antenna is included in the
touchpad spare part kit.
M27890-001
Smart card reader (not illustrated)
NOTE: The card reader cable is available in the Cable Kit as spare part number M21138-001.
M21398-001
RJ-45 door (not illustrated)
Slim N09823-001
Nonslim N09822-001
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Display assembly subcomponents
21
