Item Component Spare part number
(5) Display cable (spared with the cable kit)
(6) Hinge covers (spared with the plastics kit)
(7) Hinges 821674-001
(8) WWAN antenna (spared with back cover)
(9) WLAN antenna (spared with back cover)
(10) Back cover (includes antennas) 821672-001
Plastics kit
Item Component Spare part number
Plastics kit 821675-001
(1) Fingerprint reader blank (includes bracket)
(2) SD card blank
(3) Hinge covers
Silicone rubber bumpers (not shown)
22 Chapter 3 Illustrated parts catalog
