SSD
Description Spare part number
Solid-state drive
512 GB, SATA-3 TLC 840635-001
256 GB, PCIe 2x4 826639-001
256 GB, SATA-3 self-encrypting drive 826641-001
256 GB, SATA-3 826640-001
240 GB, SATA-3 822220-001
180 GB, SATA-3, self-encrypting drive 826637-001
180 GB, SATA-3 MLC 826636-001
128 GB, SATA-3 TLC 826635-001
Before removing the SSD, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 32).
5. Disconnect the battery (see Battery on page 35).
Remove the SSD:
1. Remove the Phillips PM2.0×3.0 screw (1) that secures the drive to the system board.
38 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
