HP EliteBook 725 G3 Series

Mass storage devices
Item Component Spare part number
(1) Hard drive
1 TB, 5400 rpm, 7 mm 762990-001
500 GB, 7200 rpm, 7 mm, FIPS 820572-001
500 GB, 7200 rpm, 7 mm, Opal-2 820573-001
500 GB, 7200 rpm, 7 mm 703267-001
500 GB, 5400 rpm, 7 mm, hybrid, 8 GB cache 732000-001
(2) Hard drive hardware kit 821665-001
(3) Solid-state drive (SSD)
512 GB, SATA-3 TLC 840635-001
256 GB, PCIe 2x4 826639-001
256 GB, SATA-3 self-encrypting drive 826641-001
256 GB, SATA-3 826640-001
240 GB, SATA-3 822220-001
180 GB, SATA-3, self-encrypting drive 826637-001
24 Chapter 3 Illustrated parts catalog
