HP EliteBook 725 G3 Series User Manual

Display assembly
Description Spare part number
Display panel assembly, touch screen 821657-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 32).
5. Remove the battery (see Battery on page 35).
Remove the display assembly:
1. Position the computer upside down.
2. Disconnect the display cable from the system board.
Component replacement procedures 61

HP EliteBook 725 G3 Series Specifications

General

RAM	Up to 16 GB DDR3L-1600 SDRAM
Processor	AMD PRO A12-8800B
Display	12.5" diagonal HD (1366 x 768)
Storage	512 GB SSD
Graphics	AMD Radeon R7
Operating System	Windows 10 Pro 64
Battery	3-cell, 46 Wh Li-ion
Ports	1 USB 3.0; 1 USB 3.0 charging; 1 USB Type-C; 1 DisplayPort; 1 VGA; 1 headphone/microphone combo; 1 RJ-45; 1 docking connector
Wireless	Intel Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth 4.2 Combo
