HP EliteBook 725 G3 Series User Manual

4. Remove the WWAN module (3) by pulling the module away from the slot at an angle.
NOTE: WWAN modules are designed with a notch to prevent incorrect insertion.
NOTE: If the WWAN antennas are not connected to the terminals on the WWAN module, the protective
sleeves must be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WWAN module.
Component replacement procedures 45

HP EliteBook 725 G3 Series Specifications

General

RAM	Up to 16 GB DDR3L-1600 SDRAM
Processor	AMD PRO A12-8800B
Display	12.5" diagonal HD (1366 x 768)
Storage	512 GB SSD
Graphics	AMD Radeon R7
Operating System	Windows 10 Pro 64
Battery	3-cell, 46 Wh Li-ion
Ports	1 USB 3.0; 1 USB 3.0 charging; 1 USB Type-C; 1 DisplayPort; 1 VGA; 1 headphone/microphone combo; 1 RJ-45; 1 docking connector
Wireless	Intel Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth 4.2 Combo
