Item Component Spare part number
(10) Touchpad
Touchpad board 821668-001
Touchpad board with NFC antenna 821667-001
(11) NFC module (includes NFC cable and NFC antenna) 821666-001
(12) Fingerprint reader board (includes cable)
NOTE: The ngerprint reader bracket is included in the Plastics Kit, spare part number
821675-001.
821693-001
(13) Heat sink/fan assembly 821691-001
(14) System board (includes processor and replacement thermal material, see System board on page 61)
Includes Intel i7-7600U processor 914274-xxx
Includes Intel i7-7500U processor 914273-xxx
Includes Intel i5-7300U processor 914272-xxx
Includes Intel i5-7200U processor 914271-xxx
Includes Intel i3-7100U processor 914270-xxx
(15) RTC battery 702853-001
(16) Speaker assembly (includes cable) 821684-001
(17) Bottom cover 821662-001
18 Chapter 3 Illustrated parts catalog
