RTC battery
Description Spare part number
RTC battery 702853-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 30).
5. Remove the battery (see Battery on page 35).
6. Remove the system board (see System board on page 61).
Remove the RTC battery:
1. Remove the RTC battery cable from the system board (1).
2. Lift the battery up to disengage it from the system board (2).
Reverse this procedure to install the RTC battery.
Component replacement procedures 65
