HP EliteDesk 800 G2 Desktop Mini Hardware Reference Guide

Connecting the AC power cord
When connecting the AC adapter, it is important to follow the steps below to ensure the power cord does not
pull free from the computer.
1. Connect the female end of the AC power cord to the AC adapter (1).
2. Plug the other end of the AC power cord into an AC outlet (2).
3. Connect the round end of the AC adapter cord to the power connector on the rear of the computer (3).
4. Route the AC adapter cord through the retainer clip to prevent the AC adapter cord from becoming
disconnected from the computer (4).
CAUTION: Failure to secure the AC adapter cord with the retainer clip may result in the adapter cord
becoming disconnected and loss of data.
Connecting the AC power cord 9

HP EliteDesk 800 G2 Desktop Mini Specifications

General

Chipset	Intel Q170
Graphics	Intel HD Graphics 530
Form Factor	Mini PC
CPU Options	Intel Core i7-6700T, Intel Core i5-6500T, Intel Core i3-6100T
RAM	DDR4-2133 MHz
Memory Capacity	Up to 32 GB
Storage	SATA HDD/SSD, M.2 SSD
Storage Options	500GB HDD, 1TB HDD, 128GB SSD, 256GB SSD, 512GB SSD
Operating System	Windows 10 Pro
OS Options	Windows 10 Pro 64, Windows 10 Home 64, FreeDOS 2.0
Ports	1 x RJ-45, 2 x DisplayPort, 1 x VGA, 1 x headphone/microphone combo
Wireless	Intel Dual Band Wireless-AC 8260, Bluetooth 4.2
Dimensions	17.7 x 17.5 x 3.4 cm
Weight	1.3 kg
Processor	Intel Core i5-6500
