HP EliteDesk 800 G2 Desktop Mini Hardware Reference Guide

Attaching the computer to a mounting xture
The computer can be attached to a wall, swing arm, or other mounting xture.
NOTE: This apparatus is intended to be supported by UL or CSA Listed wall mount bracket.
1. If the computer is on a stand, remove the computer from the stand and lay the computer down.
2. To attach the computer to a swing arm (sold separately), insert four screws through the holes on the
swing arm plate and into the mounting holes on the computer.
CAUTION: This computer supports the VESA industry standard 100 mm mounting holes. To attach a
third-party mounting solution to the computer, use the screws that are supplied with the solution. It is
important to verify that the manufacturer’s mounting solution is compliant with the VESA standard and
is rated to support the weight of the computer. For best performance, it is important to use the power
and other cables provided with the computer.
To attach the computer to other mounting xtures, follow the instructions included with the mounting
xture to ensure that the computer is safely attached.
40 Chapter 2 Hardware upgrades

HP EliteDesk 800 G2 Desktop Mini Specifications

General

Chipset	Intel Q170
Graphics	Intel HD Graphics 530
Form Factor	Mini PC
CPU Options	Intel Core i7-6700T, Intel Core i5-6500T, Intel Core i3-6100T
RAM	DDR4-2133 MHz
Memory Capacity	Up to 32 GB
Storage	SATA HDD/SSD, M.2 SSD
Storage Options	500GB HDD, 1TB HDD, 128GB SSD, 256GB SSD, 512GB SSD
Operating System	Windows 10 Pro
OS Options	Windows 10 Pro 64, Windows 10 Home 64, FreeDOS 2.0
Ports	1 x RJ-45, 2 x DisplayPort, 1 x VGA, 1 x headphone/microphone combo
Wireless	Intel Dual Band Wireless-AC 8260, Bluetooth 4.2
Dimensions	17.7 x 17.5 x 3.4 cm
Weight	1.3 kg
Processor	Intel Core i5-6500
