Processor
Description
Intel Core i7-7700 processor
Intel Core i7-6700 processor
Intel Core i5-7600 processor
Intel Core i5-7500 processor
Intel Core i5-6600 processor
Intel Core i5-6500 processor
Intel Core i3-7320 processor
Intel Core i3-7300 processor
Intel Core i3-7100 processor
Intel Core i3-6100 processor
Intel Pentium G4600 processor
Intel Pentium G4620 processor
Intel Pentium G4560 processor
Intel Celeron G3950 processor
Intel Celeron G3930 processor
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 17).
2. Remove the base unit rear and front access panels (see Base unit access covers on page 18).
3. Remove the fans (see Fans on page 28).
4. Remove the heat sink (see Heat sink on page 37).
5. Rotate the locking lever to its full open position (1).
38 Chapter 4 Removal and replacement procedures
