b. Remove the display bezel (4).
The display bezel is available using spare part number 698077-001.
6. If it is necessary to replace the webcam/microphone module:
CAUTION: Handle the webcam/microphone module with caution. This module has a thin
profile and is susceptible to damage when not handled carefully.
a. Release the three metallic shielding tabs (1) that secure the webcam/microphone module to
the display enclosure.
b. Release the webcam/microphone module (2) as far as the webcam/microphone
module allows.
Component replacement procedures 65
