2. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module. (The
edge of the module opposite the slot rises away from the computer.)
3. Remove the memory module (2) by pulling the module away from the slot at an angle.
NOTE: Memory modules are designed with a notch to prevent incorrect insertion.
4. Remove the bottom cover (see Bottom cover on page 28).
Reverse this procedure to install the memory module shield and memory module.
34 Chapter 5 Removal and replacement procedures
