Speakers
Table 5-16 Speakers description and spare part number information
Description Spare part number
Speakers (include left and right speakers, cables, and rubber isolators) L53561-001
Before removing the speakers, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the computer
on, and then shut it down through the operating system.
2. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 28), and then remove the following components:
a. Battery (see Battery on page 30)
b. Solid-state drive (see Solid-state drive on page 31)
c. Fans (see Fans on page 45)
d. System board (see System board on page 54)
Remove the speakers:
1. Release the power connector cable from the retention clips (1) and routing channel built into the
left speaker.
2. Release the speaker cable from the retention clips (2) and routing channel built into the keyboard/
top cover.
62 Chapter 5 Removal and replacement procedures
