HP G62 User Manual

Linux backup and recovery
Use the instructions in this section if SUSE Linux SLED 11 is installed on the computer.
To protect your information, back up your files and folders. Then if the system fails, restore your
important files from copies. Use the options listed in this section to restore the operating system and
programs that were installed at the factory.
CAUTION: Using f11 completely erases hard drive contents and reformats the hard drive. All files
created and any software installed on the computer are permanently removed. The f11 recovery tool
reinstalls the original operating system and HP programs and drivers that were installed at the
factory. Software, drivers, and updates not installed by HP must be manually reinstalled. Personal
files must be restored from a backup.
To recover the original hard drive image using f11:
1. If possible, back up all personal files.
2. Restart the computer, and then press f11 while the “Press <F11> for recovery” message
appears on the screen.
3. Follow the on-screen instructions.
NOTE: If you are unable to boot (start up) the computer from the primary operating system or from
the recovery f11 method, purchase a SUSE Linux Enterprise Desktop Operating System DVD to
repair the operating system. For additional information, see the Worldwide Telephone Numbers
booklet, included with the computer.
106 Chapter 7 Backup and recovery

HP G62 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-330M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
LightScribe	Yes
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Pixel pitch	0.259 x 0.259 mm
Display diagonal	15.6 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Display number of colors	16.78 million colors
Discrete graphics card model	AMD Mobility Radeon HD 5430
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	667 MHz
Audio system	-
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad + Scroll zone
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Processor code	SLBNF
Processor ARK ID	47663
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
Cable lock slot type	Kensington
Cables included	AC
Package depth	109 mm
Package width	521 mm
Package height	345 mm
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	246 mm
Width	374 mm
Weight	2500 g
Height (rear)	36.8 mm
Height (front)	31.8 mm
