Keyboard
Description Spare part number
For use in Adriatics 605922-BA1
For use in Belgium 605922-A41
For use in the Czech Republic 605922-221
For use in France 605922-051
For use in Germany 605922-041
For use in Greece 605922-DJ1
For use in Hungary 605922-211
For International use 605922-B31
For use in Israel 605922-BB1
For use in Italy 605922-061
For use in North America 605922-001
For use in Norway 605922-DH1
For use in Portugal 605922-131
For use in Russia 605922-251
For use in Saudi Arabia 605922-171
For use in Spain 605922-071
For use in Switzerland 605922-BG1
For use in Turkey 595199-141
For use in the United Kingdom 595199-031
Before removing the keyboard:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn on
the computer, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC
outlet and then disconnecting the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Remove the hard drive (see
Hard drive on page 42).
6. Remove the WLAN/Memory Module compartment cover (see
WLAN module on page 47).
Remove the keyboard:
1. Turn the computer upside down with the front toward you.
Component replacement procedures 53

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP G62 and is the answer not in the manual?

HP G62 Specifications

General IconGeneral
Bus typeDMI
SteppingC2
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli3-330M
System bus rate2.5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-300 Mobile Series
Processor socketBGA 1288
Processor threads4
Processor codenameArrandale
Processing Die size81 mm²
Processor frequency2.13 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16
Thermal Design Power (TDP)35 W
Maximum number of PCI Express lanes16
Number of Processing Die Transistors382 M
Motherboard chipsetIntel® HM55 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)2 x 2 GB
LightScribeYes
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Total storage capacity320 GB
Compatible memory cardsMemory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed1
Pixel pitch0.259 x 0.259 mm
Display diagonal15.6 \
Display brightness200 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Contrast ratio (typical)300:1
Display number of colors16.78 million colors
Discrete graphics card modelAMD Mobility Radeon HD 5430
On-board graphics card modelIntel® HD Graphics
Discrete graphics card memory0.512 GB
On-board graphics card base frequency500 MHz
On-board graphics card dynamic frequency (max)667 MHz
Audio system-
Speakers manufacturerAltec Lansing
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Pointing deviceTouchpad + Scroll zone
Operating system installedWindows 7 Home Premium
Form factorClamshell
Product typeLaptop
Product colorBlack, Silver
Country of originChina
Processor codeSLBNF
Processor ARK ID47663
Processor package sizerPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography45 nm
Supported instruction setsSSE4.1, SSE4.2
Battery life (max)- h
Number of battery cells6
AC adapter power90 W
Cable lock slot typeKensington
Cables includedAC
Package depth109 mm
Package width521 mm
Package height345 mm
Operating altitude-15 - 3048 m
Non-operating altitude-15 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth246 mm
Width374 mm
Weight2500 g
Height (rear)36.8 mm
Height (front)31.8 mm
