RJ-11 (modem)
Pin Signal
1 Unused
2Tip
3Ring
4 Unused
5 Unused
6 Unused
RJ-45 (network)
Pin Signal
1 Transmit +
2 Transmit -
3Receive +
4 Unused
5 Unused
6Receive -
7 Unused
8 Unused
RJ-11 (modem) 109
