10 Recycling
Battery
When a battery has reached the end of its useful life, do not dispose of the battery in general
household waste. Follow the local laws and regulations in your area for computer battery disposal.
Display
WARNING! The backlight contains mercury. Exercise caution when removing and handling the
backlight to avoid damaging this component and causing exposure to the mercury.
CAUTION: The procedures in this chapter can result in damage to display components. The only
components intended for recycling purposes are the liquid crystal display (LCD) panel and the
backlight. When you remove these components, handle them carefully.
NOTE: Materials Disposal. This HP product contains mercury in the backlight in the display
assembly that might require special handling at end-of-life. Disposal of mercury might be regulated
because of environmental considerations. For disposal or recycling information, contact your local
authorities, or see the Electronic Industries Alliance (EIA) Web site at
http://www.eiae.org.
This section provides disassembly instructions for the display assembly. The display assembly must
be disassembled to gain access to the backlight (1) and the liquid crystal display (LCD) panel (2).
NOTE: The procedures provided in this chapter are general disassembly instructions. Specific
details, such as screw sizes, quantities, and locations, and component shapes and sizes, can vary
from one computer model to another.
114 Chapter 10 Recycling

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP G62 and is the answer not in the manual?

HP G62 Specifications

General IconGeneral
Bus typeDMI
SteppingC2
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli3-330M
System bus rate2.5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-300 Mobile Series
Processor socketBGA 1288
Processor threads4
Processor codenameArrandale
Processing Die size81 mm²
Processor frequency2.13 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16
Thermal Design Power (TDP)35 W
Maximum number of PCI Express lanes16
Number of Processing Die Transistors382 M
Motherboard chipsetIntel® HM55 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)2 x 2 GB
LightScribeYes
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Total storage capacity320 GB
Compatible memory cardsMemory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed1
Pixel pitch0.259 x 0.259 mm
Display diagonal15.6 \
Display brightness200 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Contrast ratio (typical)300:1
Display number of colors16.78 million colors
Discrete graphics card modelAMD Mobility Radeon HD 5430
On-board graphics card modelIntel® HD Graphics
Discrete graphics card memory0.512 GB
On-board graphics card base frequency500 MHz
On-board graphics card dynamic frequency (max)667 MHz
Audio system-
Speakers manufacturerAltec Lansing
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10, 100 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Pointing deviceTouchpad + Scroll zone
Operating system installedWindows 7 Home Premium
Form factorClamshell
Product typeLaptop
Product colorBlack, Silver
Country of originChina
Processor codeSLBNF
Processor ARK ID47663
Processor package sizerPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography45 nm
Supported instruction setsSSE4.1, SSE4.2
Battery life (max)- h
Number of battery cells6
AC adapter power90 W
Cable lock slot typeKensington
Cables includedAC
Package depth109 mm
Package width521 mm
Package height345 mm
Operating altitude-15 - 3048 m
Non-operating altitude-15 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth246 mm
Width374 mm
Weight2500 g
Height (rear)36.8 mm
Height (front)31.8 mm
