Item Description Spare part number
●
White computer models 610563-001
●
Red computer models 615437–001
●
Blue computer models 615438–001
(16) Battery
●
6-cell Li-lon, 2.20 Ah, 47 Wh 593553-001
●
6-cell Li-lon, 2.55 Ah, 55 Wh 593554-001
(17) Power connector (includes cable) 609154-001
(18) USB board 606011-001
(19) RJ-11 connector included in Cable Kit 606009-001
(20) Bluetooth module (for model 1.0 only) 537921–001
Bluetooth module cable 605904–001
(21) Base enclosure for use with:
●
Matte black computer models 606018-001
●
Biscotti computer models 610564-001
●
Silver computer models 610565-001
●
White computer models 610566-001
●
Red computer models 615427-001
●
Blue computer models 615428-001
Rubber Kit (not illustrated, includes four rubber feet) 606012-001
Plastics Kit 606006-001
(21)
●
Hard drive cover
(23)
●
Memory module cover
22 Chapter 3 Illustrated parts catalog
