Spare part number Description

594188-001 Intel Arrandale i5–540M Processor (2.53 GHz, 3 MB total L3 cache, 1066 MHz)—Dual core 35

595130-001 High Definition display panel (includes display panel and backlight cables)

597622-001 Intel Arrandale i3–330 Processor (2.13 GHz, 3 MB L3 cache, 1066 MHz)—Dual Core 35 W (for

model 1.0 only)

597623-001 Intel Arrandale i3–350 Processor (2.26 GHz, 3 MB L3 cache, 1066 MHz)—Dual Core 35 W

597624-001 Intel Arrandale i5–430 Processor (2.26 GHz, 3 MB total L3 cache, 1066 MHz)—Dual Core 35 W

598856-001 2 GB memory module (1066 MHz, DDR3)

598859-001 1 GB memory module (1066 MHz, DDR3)

599092-001 4 GB memory module (1066 MHz, DDR3) (for model 1.1 only)

600370-001 Broadcom 4313 802.11b/g/n 1x1 WiFi and 2070 Bluetooth 2.1+EDR Combo adapter

(BT3.0+HS ready) (for model 1.1 only)

602992-001 Ralink RT3090BC4 802.11b/g/n 1x1 WiFi and Bluetooth 2.1+EDR Combo Adapter (BT3.0+HS

ready) (for model 1.1 only)

605902–001 HD 5470/512 MB discrete system board with card reader

605903-001 HD UMA system board with card reader

605904-001 Bluetooth module cable

605906-001 39.6-cm (15.6-in) HD, light-emitting diode display assembly for HP G62 biscotti computer

models

605907-001 39.6-cm (15.6-in) HD, light-emitting diode display assembly for HP G62 silver computer models

605908-001 39.6-cm (15.6-in) HD, light-emitting diode display assembly for HP G62 white computer models

605910-001 Display back cover for use with HP G62 biscotti computer models

605911-001 Display back cover for use with HP G62 silver computer models

605912-001 Display back cover for use with HP G62 white computer models

605913-001 Display bezel

605915–001 Display hinge kit (includes left and right display hinges)

605916-001 Webcam module cable

605917-001 Display rubber kit

605918-001 Display screw kit

605919-001 Hard Drive Hardware Kit (includes bracket and screws)

605920-001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe for use with

matte black computer models

605921-001 Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive for use with matte

black computer models

605922–001 Keyboard for use in North America (includes keyboard cable)

605922–031 Keyboard for use in the United Kingdom (includes keyboard cable)

605922–041 Keyboard for use in Germany (includes keyboard cable)

30 Chapter 3 Illustrated parts catalog

Questions and Answers:

Need help?

Do you have a question about the HP G62 and is the answer not in the manual?

HP G62 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-330M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
LightScribe	Yes
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Pixel pitch	0.259 x 0.259 mm
Display diagonal	15.6 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Display number of colors	16.78 million colors
Discrete graphics card model	AMD Mobility Radeon HD 5430
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	667 MHz
Audio system	-
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad + Scroll zone
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Processor code	SLBNF
Processor ARK ID	47663
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
Cable lock slot type	Kensington
Cables included	AC
Package depth	109 mm
Package width	521 mm
Package height	345 mm
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
