Spare part number Description
608340–001 HD 5470/1 G discrete system board with card reader
608444–001 39.6-cm (15.6-in) HD, light-emitting diode display assembly for HP G62 matte black computer
models
608445–001 Display back cover for use with HP G62 matte black computer models
609154–001 Power connector (includes cable)
609939–001 65-W AC adapter
609940–001 90-W AC adapter
610558–001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe for use with
biscotti computer models
610559–001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe for use with
silver computer models
610560–001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe for use with
white computer models
610561–001 Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive for use with biscotti
computer models
610562–001 Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive for use with silver
computer models
610563–001 Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive for use with white
computer models
610564–001 Base enclosure with HDMI card reader for biscotti computer models
610565–001 Base enclosure with HDMI card reader for silver computer models
610566–001 Base enclosure with HDMI card reader for white computer models
610567–001 Top cover (includes TouchPad board) for use in biscotti computer models
610568–001 Top cover (includes TouchPad board) for use in silver computer models
610569–001 Top cover (includes TouchPad board) for use in white computer models
610583–001 500 GB, 7200 rpm hard drive
613584-001 Intel Arrandale i3–370 Processor (2.4 GHz, 3 MB L3 cache, 1066 MHz)—Dual Core 35 W
613585-001 Intel Arrandale i5–450 Processor (2.4 GHz, 3 MB L3 cache, 1066 MHz)—Dual Core 35 W
613586-001 Pentium Arrandale P6000 Processor (1.86 GHz, 3 MB L3 cache, 1066 MHz)—Dual Core 35 W
613587-001 Pentium Arrandale P6100 Processor (2.0 GHz, 3 MB L3 cache, 1066 MHz)—Dual Core 35 W
(for model 1.1 only)
615076–001 160 GB, 7200 rpm hard drive
615381–001 HD 5470/ 512 MB discrete system board with card reader (for model 1.1 only)
615382–001 HD 5470/1 G discrete system board with card reader (for model 1.1 only)
615423–001 39.6-cm (15.6-in) HD, light-emitting diode display assembly for HP G62 red computer models
615424–001 39.6-cm (15.6-in) HD, light-emitting diode display assembly for HP G62 blue computer models
615425–001 Display back cover for use with HP G62 red computer models
615426–001 Display back cover for use with HP G62 blue computer models
32 Chapter 3 Illustrated parts catalog

HP G62 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-330M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
LightScribe	Yes
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Pixel pitch	0.259 x 0.259 mm
Display diagonal	15.6 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Display number of colors	16.78 million colors
Discrete graphics card model	AMD Mobility Radeon HD 5430
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	667 MHz
Audio system	-
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad + Scroll zone
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Processor code	SLBNF
Processor ARK ID	47663
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
Cable lock slot type	Kensington
Cables included	AC
Package depth	109 mm
Package width	521 mm
Package height	345 mm
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	246 mm
Width	374 mm
Weight	2500 g
Height (rear)	36.8 mm
Height (front)	31.8 mm
