HP G72 User Manual

5. Disconnect the webcam cable (5) from the system board and release it from the clips that attach
it to the system board.
CAUTION: Support the display assembly when removing the display screws in the following
steps. Failure to support the display assembly can result in damage to the assembly and other
components.
6. Remove the five black Phillips PM2.5×7.0 screws (1) that secure the display assembly to the
computer.
7. Lift the display panel (2) straight up to remove it.
Reverse this procedure to install the display assembly.
Component replacement procedures 69

HP G72 Specifications

General

Display Size	17.3 inches
Resolution	1600 x 900
Graphics	Intel HD Graphics or ATI Mobility Radeon HD 5470
Wireless	802.11 b/g/n
Battery	6-cell Lithium-Ion
Operating System	Windows 7
Weight	6.6 lbs (3 kg)
Optical Drive	DVD±RW
Networking	10/100 Ethernet
Ports	3 x USB 2.0, HDMI, VGA
RAM	Up to 8 GB DDR3
