5.1 home audio installation
The following diagram shows a typical advanced
home theater audio six-channel 6/5.1 speaker
installation that requires multichannel inputs on a
receiver/amplifier.
This is only a suggested configuration. Your system
may be different.
PC to 5.1 multichannel audio system connection
OUT
IN
A
B
C
DE F G
n
A: PC back-panel
connectors (type 3,
type 6, or sound
card)
B: Y adapter cables
C: Receiver/amplifier
D: Subwoofer
E: enter speaker
F: Front speakers
(left and right)
G: Rear speakers
(left and right)
