HP HPE StoreOnce 3100 Series

Using LEDs to diagnose problems
Server LEDs (all models)
Front panel LEDs
Figure 7 Front panel LEDs, HPE StoreOnce 3100 System
3 4
1 2 3 4
NIC status LED2UID LED1
Power LED and on/off button4System health LED3
Figure 8 Front panel LEDs, HPE StoreOnce 3500 Series and HPE StoreOnce 5100 System
1
2
3
4
Power LED and on/off button2System health LED1
UID LED4NIC status LED3
Front panel LEDs and buttons behavior
Using LEDs to diagnose problems 23
