ENWW HP Jetdirect Configuration Page 5
PORT CONFIG: Identifies the link configuration of the RJ-45 port on the
HP Jetdirect 10/100Base-TX print server:
10BASE-T HALF: 10 Mbps, half-duplex
10BASE-T FULL: 10 Mbps, full-duplex
100TX HALF: 100Mbps, half-duplex
100TX-FULL: 100Mbps, full-duplex
UNKNOWN: The print server is in an initialization state.
DISCONNECTED: A network connection has not been
detected. Check network cables.
AUTONEGOTIATION Identifies whether IEEE 802.3u Autonegotiation on the
HP Jetdirect 10/100TX port is enabled (ON) or disabled
(OFF).
ON (default): the HP Jetdirect print server will attempt to
automatically configure itself onto the network at the proper
speed (10 or 100 Mbps) and mode (half or full duplex).
Autonegotiation is enabled after a cold reset.
OFF: you must manually configure the speed and mode
using the EIO menu from the printer’s control panel. If
Autonegotiation is off, the settings must match those of
the network for proper operation.
MANUFACTURING ID: The manufacturing identification code for use by HP online
support personnel.
DATE
MANUFACTURED:
Identifies the date of manufacture of the HP Jetdirect print
server.
Total Packets
Transmitted
(HP Jetdirect 802.11b wireless print servers) Total number
of frames (packets) transmitted without error.
Total Packets Received (HP Jetdirect 802.11b wireless print servers) Total number
of frames (packets) received by the HP Jetdirect print server
without error. This includes broadcast, multicast packets,
and packets specifically addressed to the print server. This
number does not include packets specifically addressed to
other nodes.
Table 9.1 HP Jetdirect Configuration (2 of 2)
Message Description
