HP J9980A User Manual

4-1
4
Switching Features
You can use the Switching pages to configure port operation and capabilities.
Port Configuration
You can use the Port Configuration pages to display port status, configure port settings, and view statistics on
packets transmitted on the port.
Port Status
The Port Status page displays the operational and administrative status of each port and enables port configu-
ration. To view this page, click Switching > Port Configuration in the navigation pane.
Figure 4-1. Port Status Page

HP J9980A Specifications

General

Category	Switch
Jumbo Frame Support	Yes
PoE	No
Layer	Layer 2
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Model	J9980A
Uplink Ports	4
MAC Address Table Size	16, 000 entries
Management	Web, SNMP, CLI
Form Factor	Rack-mountable
Power Supply	Internal
Humidity	5% to 95% (noncondensing)
