296
# Send IPv6 multicast data from Source to IPv6 multicast group FF1E::101. (Details not shown.)
# Display PIM routing entries on Router C.
[RouterC] display ipv6 pim routing-table
Total 1 (*, G) entry; 1 (S, G) entry
(*, FF1E::101)
Protocol: pim-dm, Flag: WC
UpTime: 00:04:25
Upstream interface: NULL
Upstream neighbor: NULL
RPF prime neighbor: NULL
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet1/0/1
Protocol: mld, UpTime: 00:04:25, Expires: -
(1001::100, FF1E::101)
Protocol: pim-dm, Flag: ACT
UpTime: 00:06:14
Upstream interface: Tunnel0
Upstream neighbor: FE80::A01:101:1
RPF prime neighbor: FE80::A01:101:1
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet1/0/1
Protocol: pim-dm, UpTime: 00:04:25, Expires: -
The output shows the following information:
•
Router A is the RPF neighbor of Router C.
•
IPv6 multicast data from Router A is delivered over the GRE tunnel to Router C.
IPv6 multicast forwarding over ADVPN tunnel interfaces
Network requirements
As shown in Figure 83:
•
An IPv6 ADVPN tunnel is established between each spoke and hub.
•
All hubs and spokes support IPv6 multicast. IPv6 PIM-SM runs on them, and NBMA runs on
their IPv6 ADVPN tunnel interfaces.
•
OSPFv3 runs all hubs and spokes.
Configure the routers so that Spoke 1 can receive IPv6 multicast data from the source.
