HP Kayak XU800 Service Handbook

HP Kayak XU800 PC Workstation
1-16 HP Kayak XU800 PC Workstation Minitower
PC Workstations
1
Parts List
Item Description Repl.
Part Number
Exchange
Part Number
1 Chassis assembly (including top cover):
a Rear fan assembly
b Input/output assembly guide,
including speaker and PCI fan
c Cover lock assembly
d Minitower kit, including:
• HP logo XU800
• rubber feet
• thumbscrew cover
• I/O bracket
• CPU metal bracket and screw
• system board captive chassis screw
• tamper detect switch assembly
• hard disk drive thermal assembly
• lower bezel and upper bezel
• 5¼-inch drive blank panel
• 3½-inch drive blank panel
• 3½-inch floppy disk drive panel
• two pair of 5¼-inch long green guide
rails
• one pair 3½-inch L&R HDD short blue
guide rails
• one pair 3½-inch L&R FDD short green
guide rails
• rear fan airflow guide
e LCD status panel
Qty
1
4
2
1
1
1
1
1
1
1
1
1
2
1
1
1
5064-0435
5065-0483
5060-0484
5064-2645
5065-0433
5064-9162
—
—
—
—
—
—
2 Cables:
a SCSI U3 cable
b IDE CD-ROM cable
c Floppy disk drive cable
d CD-ROM to audio cable
e IDE HDD cable
5184-1502
5184-1515
5184-1516
5182-1857
5065-1271
—
—
—
—
—
3 Mouse:
a Three-button mouse
b Enhanced mouse with scroll/zoom wheel
C4728-60101
C4736-60101
—
—
