HP Kayak XU800 Service Handbook

HP Kayak XU800 PC Workstation
Minitower
PC Workstations
HP Kayak XU800 PC Workstation 1-17
1
4 System board
(refer to the system board parts list on the
following page for processors).
D8000-63002 D8000-69002
Processor Terminator and VRM:
a Processor connector termination card 5064-9725 —
b VRM (included in processor accessory kit) 0950-3633 —
Main memory system:
c RIMM Memory Expansion Card
(4 sockets)
5064-2526 —
d DIMM Memory Expansion Card
(4 sockets)
5065-2525 —
Main memory modules:
For RIMM sockets:
e 2 x 64 MB, 600 MHz ECC RDRAM
2 x 128 MB, 600 MHz ECC RDRAM
2 x 256 MB, 600 MHz ECC RDRAM
2 x 64 MB, 800 MHz ECC RDRAM
2 x 128 MB, 800 MHz ECC RDRAM
2x 256 MB, 800 MHz ECC RDRAM
5065-0497
5065-0496
5065-0495
D9518-63010
D9519-63010
D9520-63010
D9518-69001
D9519-69001
D9520-69001
D9518-69010
D9519-69010
D9520-69010
f RIMM continuity module D8660-63001 —
For DIMM
1
sockets:
g 128 MB (2 x 64 MB), 100 MHz ECC SDRAM
256 MB (2 x 128 MB), 100 MHz ECC SDRAM
512 MB (2 x 256 MB), 100 MHz ECC SDRAM
1 GB (2 x 512 MB), 100 MHz ECC SDRAM
D9512-63001
D9513-63001
D9514-63001
D9515-63001
D9512-69001
D9513-69001
D9514-69001
D9515-69001
5 Power supply unit 0950-3628 —
6 Floppy disk drive (1.44) D2035-60293 —
7 Hard disk drives:
9.1 GB SCSI, 7.2k rpm
9.1 GB SCSI, 7.2k rpm
9.1 GB SCSI, 10k rpm
18.1 GB SCSI,10k rpm
15 GB IDE, 7.2k rpm
D9475-63001
D6463-63003
D8608-63003
D8609-63003
D9804-63001
D9475-69001
D6463-69003
D8608-69003
D8609-69003
D9804-69001
8 Ultra 2 SCSI (optional):
a Ultra 2 SCSI card
b SCSI U2 cable
c SCSI LED cable
FastRaid (optional), not shown:
a Controller
bCable
5064-7466
5184-1501
5183-9401
5064-9766
5183-9415
—
—
—
D9661-69001
—
Parts List
Item Description Repl.
Part Number
Exchange
Part Number
