6.2 Electrical Block Diagram
6.2.1 Scalar Board
Scalar TSUM1PLR-LF
(Include ADC、OSD、MCU)
(U401)
FLASH MEMORY
PM25LV010A
(U402)
D-Sub Connector
(CN101)
EPR_SDA
EPR SCL
Panel Interface
(CN402)
EEPROM
M24C02
(U104)
H sync
V sync
RGB
DDC1_SCL
DDC1 SD
A
Crystal(14.31818MHz)
(X401)
EEPROM
M24C04-WMN6TP
(U403)
