10
Step 1 Quick release Base stand
(1) Lay the display on soft desk and push the button of stand to unlock the stand, then pull out the stand form
the monitor head.
(2) T
wist out the screw and separate base and stand.
Step 2: Strip two screws from the rear cover, then move rear cover follow the below way.
Press the black button
Twist out the screw
Dismantle the rear
cover first from the
marked position
Remove two screws
