HP MSM720 Installation Guide

Cabling specifications
Category 3, 4 or 5, 100-ohm unshielded twisted-pair (UTP) or shielded twisted-pair
(STP) cable, complying with IEEE 802.3 10BASE-T specifications.
10 Mbps
Operation
Twisted-pair
copper
Category 5, 100-ohm UTP or STP cable, complying with IEEE 802.3u 100BASE-TX
specifications.
100 Mbps
Operation
Category 5, 100-ohm 4-pair UTP or STP cable, complying with IEEE 802.3ab
1000BASE-T specifications—Category 5e or better is recommended. See Note
on 1000BASE-T Cable Requirements below.
1000 Mbps
Operation
2.5/125 mm or 50/125 mm (core/cladding) diameter, low metal content, graded
index fiber-optic cables, complying with the ITU-T G.651 and ISO/IEC 793-2
Type A1b or A1a standards respectively.*
Multimode fiber
9/125 um (core/cladding) diameter, low metal content fiber-optic cables,
complying with the ITU-T G.652 and ISO/IEC 793-2 Type B1 standards.
Single mode
fiber
*A mode conditioning patch cord may be needed for some Gigabit-LX installations. See “Mode conditioning patch
cord (fiber cables)” (page 28) for more information.
NOTE: Note on 1000BASE-T Cable Requirements:
The Category 5 networking cables that work for 100BASE-TX connections should also work for
1000BASE-T, as long as all four-pairs are connected. But, for the most robust connections, you
should use cabling that complies with the Category 5e specifications, as described in Addendum
5 to the TIA-568-A standard (ANSI/TIA/EIA-568-A-5). Because of the increased speed provided
by 1000BASE-T (Gigabit-T), network cable quality is more important than for either 10BASE-T or
100BASE-TX. Cabling plants being used to carry 1000BASE-T networking must comply with the
IEEE 802.3ab standards. In particular, the cabling must pass tests for Attenuation, Near-End
Crosstalk (NEXT), and Far-End Crosstalk (FEXT). Additionally, unlike the cables for 100BASE-TX,
the 1000BASE-T cables must pass tests for Equal-Level Far-End Crosstalk (ELFEXT) and Return Loss.
When testing your cabling, be sure to include the patch cables that connect the controller and
other end devices to the patch panels on your site. The patch cables are frequently overlooked
when testing cable and they must also comply with the cabling standards.
Cabling distance specifications
Supported distances
Multimode fiber modal
bandwidthSupported cable typeTechnology
up to 2,000 metersanymultimode fiber100-FX
0.5 - 10,000 metersN/Asingle mode fiber100-BX
up to 100 metersN/Atwisted-pair copper1000-T
2 - 220 meters160 MHz*kmmultimode fiber1000-SX
2 - 275 meters200 MHz*km
2 - 500 meters400 MHz*km
2 - 550 meters500 MHz*km
2 - 550 meters400 MHz*kmmultimode fiber100–LX
2 - 550 meters500 MHz*km
2 - 10,000 metersN/Asingle mode fiber
10 - 70,000 meters*N/Asingle mode fiber1000-LH
26 Specifications
